Hydrobox

Share

Description

HYDROBOX
Power max (kW)18
Power min-max (kW)17-7
Power transferred to the water (kW)16-6,5
Efficiency (%)90-91
Consumption min-max. (kg/h)1,6-3,8
CPower consumption (W)150-500
Heating capacity (m3)400
Hopper capacity (Kg)30
Metalic inside
Autonomous (h) (min-max)18,7-7,8
Weight (kg)180
Fume outlet diameter (mm)80
Air inlet diameter (mm)50
Working pressure (bar)1,5
Working maximum pressure (bar)2,5
Closed expansion vessel (l)6
Maximum service temperature (ºC)40/80
Valve for drinning water
Water pump
Weekly programmer
Automatic ignition
Management Heating / ACS
S2:Security systems: Safety thermostat pellet, Safety thermostat water, Air flow switch, Pressure switch, Safety valve 3 bar
Compatible accesories not includedVAL-02/VAL-04/T-AMB/CRONO-01/PE-130

Features

  • Power max: 18kw
  • Power min-max: 17-7kw
  • Power transferred to the water: 16-6,5kw
  • Efficiency: 90-91 %
  • Consumption min-max.: 1,6-3,8 kg/h
  • Power consumption: 150-500W
  • Heating capacity: 400 m3
  • Tank capacity: 30
  • Metallic interior
  • Autonomy (min-max): 18,7-7,8h
  • Weight: 180kg
  • Fume outlet diameter: 80mm
  • Air inlet diameter: 50mm
  • Working pressure: 1,5bar
  • Working maximum pressure: 2,5bar
  • Closed expansion vessel: 6l
  • Maximum service temperature: 40/80°C
  • Valve for drinning water
  • Circulating pump
  • Weekly programmer
  • Automatic ignition
  • Hermetic tank
  • Management Heating / Sanitary Water
  • Security system: S2. Safety thermostat pellet, Safety thermostat water, Air flow switch, Safety valve 3 bar, Pressure setting valve
  • Compatible accesories not included: VAL-02/VAL-04/T-AMB/CRONO-01/PE-130
  • New patented heat exchange system.
  • Black heat resistant paint and epoxy paint coating.
  • Cast-iron burner
  • Thermally insulated chamber.
  • Combustion chamber window.
  • Automatic air vent included.
  • Door with vermiculite interior and viewer with double glass
  • Exterior door with vermiculite interior.
  • Exterior door with thermal insulation.
  • Grafic LCD color Touch of 3.5”for programming and controlling the boiler.
  • Height adjustable levelling feet.
  • Ease of access to cleaning and maintenance tasks.
Click to enlarge

Additional information

Fuel Type

Manufacturer

Power (kW)

Stove Type

,
