DIMENSIONS (HXWXD) 641X715X655
WEIGHT (KG) 154
HEATABLE AREA (M²)*A*C 128
EFFICIENCY UP TO MAX (%)*A 91,4%
ENERGY CLASS A+
POWER TO THE HEART (KW)*A 5,5 – 15,7
RATED POWER (KW)*A 5 – 14,2
POWER TO THE WATER (KW)*A 4,4 – 11,8
RADIATION (KW)*A 0,7 – 2,4
HOURLY PELLET CONSUMPTION (KG/H)*A 1,1 – 3,3
WOOD HOURLY CONSUMPTION (KG/H)*A –
PELLET HOPPER CAPACITY (KG)*A 20,0
WARM AIR DUCTING –
MAXIMUM SINGLE DUCTING OUTLET (M) –
PATENTED BURNER PELLETPOWER® SI
ROOM VENTILATION –
PRIMARY AIR FROM OUTSIDE SI
CO EMISSIONS (MG/M³; 13% OF O2)*A 104,3
CO EMISSIONS (MG/M³; 10% OF O2)*A –
DUST EMISSIONS (MG/M³; 13% OF O2)*A 14,9
DUST EMISSIONS (MG/M³; 10% OF O2)*A –
SILENCE (DB) 36
REMOTE CONTROL –
RADIO CONTROL WITH ROOM TEMPERATURE THERMOSTAT –
WEEKLY PROGRAMMER (3 DAILY LIGHTING) SI
«SMART INFO» FUNCTION SI
SYSTEM CIRCULATING PUMP SI
EXPANSION TANK SI
OVER PRESSURE VALVE SI
FLUE GASEXHAUST DIAMETER (MM) 80
MIN. FLUE DRAUGHT PRESSURE (PA) 10
ELECTRIC CONSUMPTION (WATT) 90-340
HIGH TEMPERATURE SAFETY THERMOSTAT SI
*A EMISSIONS AND PERFORMANCE DATA MAY CHANGE ACCORDING TO THE FUEL USED. THE VALUES OF PELLET PRODUCTS HAVE BEEN OBTAINED BY USING CERTIFIED FUEL ACCORDING TO EN 14961-2 A1-A2 NORM. WOOD LOGS PRODUCTS VALUES MAY VARY ACCORDING TO THE TYPE AND QUALITY OF THE WOOD LOGS USED.
*B PROVISIONAL DATA UNDER CERTIFICATION
*C IMPORTANT: WHEN CALCULATING THE VOLUME OF THE “HEATED AREA” SOME RELEVANT ASPECTS MUST BE CONSIDERED: INSULATION OF THE BUILDING (ENERGY CLASS), POSITION OF THE HEATER, CLIMATIC AREA AND MORE ASPECTS THAT CAN AFFECT THE VALUES OF PERFORMANCE. REPORTED DATA HAVE BEEN CALCULATED ON THE BASE OF ROOF NOT HIGHER THAN 3 MTS.
THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES WITHOUT PREVIOUS NOTICE.
