Madrid Vision

Categories: , , , Tag:

Description

MADRID VISION
Power (kW)19
Efficiency (%)75
Consumption (kg/h)5.06
Heating capacity (m3)475
Cast-iron inside
Manufactured in cast-iron
Weight (kg)205
Smoke exit tube diameter (mm)200
Air channel (diameter and exit tube number)2 X 120
Forced ventilation2 X 160
Clean glass system
Useful chamber measures690 X 330 X 390
Maximum logs size (cm)65
Double combustion
Compatible accesories not includedM-68; M-69; M-70; M-71
Features:
  • Heating power: 19kw
  • Power min-max: kw
  • Efficiency (%): 75%
  • Consumption (kg/h): 5.06kg/h
  • Heating capacity (m3): 475m3
  • Cast-iron interior
  • Manufactured in cast-iron
  • Weight (kg): 205kg
  • Smoke exit tube diameter (mm): 200mm
  • Air channel (diameter and exit tube number): 2 X 120
  • Forced ventilation: 2 X 160
  • Clean glass system
  • Useful chamber measures: 690 X 330 X 390mm
  • Maximum logs size (cm): 65cm
  • Double combustion
  • Compatible accesories not included: M-68; M-69; M-70; M-71
